Whirlpool Washer Error Codes: Full Guide

Whirlpool washing machines display error codes when the control board detects something outside normal operation. These codes help you (and your technician) skip the guesswork and go straight to diagnosing the problem. Here's a comprehensive guide to the most common Whirlpool washer error codes and what they mean.

How to Access Error Codes

On most Whirlpool washers, error codes appear automatically on the display when a fault is detected. To access stored fault codes on many models, turn the selector dial to Normal, then rotate it counterclockwise one click, clockwise three clicks, counterclockwise one click, and clockwise one click. The lights will cycle, and fault codes will display. Always check your specific model's manual for the exact procedure.

Common Whirlpool Washer Error Codes

F0 E1 --- Load Detected During Clean Washer Cycle

The washer detected items in the drum during a Clean Washer cycle. Remove all items and run the cycle again on an empty drum.

F1 E1 --- Main Control Board Fault

The main electronic control board has experienced a fault. Try a power reset. If the code returns, the control board likely needs replacement --- a job for a technician.

F1 E2 --- Motor Control Fault

The motor control unit has reported an error. This may mean the motor itself, the motor control board, or the wiring between them needs attention.

F2 E1 --- Keypad / User Interface Fault

One or more buttons on the control panel are stuck or not responding. Check for anything pressing against the panel. If the panel itself is faulty, it needs replacement.

F3 E1 --- Pressure Sensor Fault

The water level pressure sensor has reported an error. This can cause overfilling or underfilling. The sensor or its air hose connection may need to be inspected or replaced.

F5 E1 --- Lid Switch Fault (Top-Load)

The lid switch is not detecting that the lid is properly closed. Check that the lid closes completely and the latch engages. If the switch itself has failed, it needs replacement.

F5 E2 --- Lid Lock Fault

The lid lock mechanism is not operating correctly. The washer won't run if it can't confirm the lid is locked. Check for obstructions preventing the lid from closing fully. If the lock mechanism is faulty, it needs replacement.

F6 E2 / F6 E3 --- Communication Fault

The main control board and the motor control board have lost communication. Check wiring connections between boards. If connections are secure, one of the boards may be faulty.

F7 E1 --- Basket Speed Sensor Fault

The sensor that monitors drum speed is reporting an error. This affects spin and agitation control. The sensor or its wiring typically needs replacement.

F8 E1 --- Water Supply Issue (Long Fill)

The washer is taking too long to fill with water. Check that both supply valves are fully open, inspect the inlet hoses for kinks, and check if the inlet valve screens are clogged with mineral deposits. Clean or replace the screens as needed.

F8 E2 --- Dispenser System Fault

The dispenser actuator motor has a fault. This affects detergent and fabric softener dispensing. The dispenser motor or its wiring may need replacement.

F9 E1 --- Long Drain

The washer is taking more than 8 minutes to drain. Check the drain hose for kinks or clogs, clean the pump filter (front-loaders), and verify the standpipe height isn't too low.

Quick Reference: Most Common Codes

• F8 E1 --- Water supply issue (check inlet hoses and valves)
• F9 E1 --- Long drain (check drain hose and pump filter)
• F5 E1 / F5 E2 --- Lid switch or lock fault
• F1 E1 --- Control board fault (requires technician)
